GitLab CI/CD

  • These are the essential building blocks:

  • Pipelines , Stages and Jobs

  • A pipeline is essentially a series of processes, called Jobs, that get executed in Stages and in a particular order depending on the defined .gitlab-ci.yml file

define job

job1:
    script:
        - echo "this is job1"
        - echo "step 2 of this top"
job2:
    script:
        - echo "this is job2"
        - echo "as of now, they will run parallely"

stage

  • run your jobs in sequence
stages:
    - build
    - test
job1:
    stage: build
    script:
        - echo "ADD STAGE:NAME TAG IN YOUR JOBS TO LINK THEM"
        - echo "NOW THIS RUNS FIRST"
job2:
    stage: test
    script:
        - echo "this is job2"
        - echo "now they will, run after job1"

before and after script

  • if before and after are defined outside any job, it will be global then
  • before_script to perfrom something before the main job like preparing the environment
  • after_script to perform something after the main job like cleanup of environment
job1:
    before_script:
        - echo "i am preparing the environment"
    script:
        - echo "hello world"
    after_script:
        - echo "i am cleaing up the environment"

variables in pipeline

  • gitlab provides pre-defined variables
  • variables can be defined in multiple ways in gitlab
# this is a globally defined variable
variables:
    key: "value"
    key2: "value"


build:
    script:
        - echo "this will echo global variable $key"
-----------------------------------------------------------------------------
# this is a local variable which is job specific
some-job:
    variables:
        KEY: "job-specific"
        KEY2: "yeah"
    script:
        - echo " upper variables are this job specific only"
-----------------------------------------
variables:
    MYVAR:
        value: "true"   #default value
        description: "this variable allow user to define its value when running pipeline"
---------------------------------------------
# Drop Down variable
variables:
    MYVARSS:
        value: "build"
        options:
            - "test"
            - "prod"
            - "build"
        description: "give user a drop down menu to choose variables from"
-------------------------------------------------
# SECRETS,TOKENS,API_KEYS,SENSITIVE VARIABELS can be defined in project/group setting of gitlab
- projects -> settings -> variables -> ADD
- there are two types
    - visible: will print the value in logs
    - masked: will show [MASKED] in logs
- Protect_Variables: if selected will only be available for protected branches else will be available for all branches
- Expand_Variable: if there is any $ in the variable, it will refrence the value of it, if unchecked it will treat $ as string


--------------------------------------------

dependency in pipeline

  • needs can be used to define the dependency in between the jobs
job1:
    script:
        - echo "hello"
job2:
    needs:
        - job1
    script:
        - echo "hi"

job execution with WHEN

  • when keyword has multiple options like:
    • on_success -> defaults - run if all previous succeed
    • on_failure -> run only if any previous job failed
    • always -> run regardless of success/failure
    • manual -> requires manual approval from gitlab ui
    • delayed -> run after a timer
job3:
  stage: deploy
  script:
    - echo "Deploying app"
  when: manual

pipeline execution control with workflow:rules

  • workflow rules controls the criteria when can a pipeline be executed and when not
  • the whole idea is simply define the rules in if and weather it should be executed or not
workflow:
    rules:
        - if: '$CI_COMMIT_BRANCH == "main"'
          when: always
        - if: '$CI_COMMIT_BRANCH == "/^feature/'
          when: always
        - when: never

job level execution control job:rules

  • more control on job level execution
  • rules are checked top to bottom and first match wins
  • we have:
    • if: -> rules based on variables
    • changes: -> run job only if specific files changed
    • exists: -> run if specific file(s) exist in repo
job_name:
  stage: test
  script: echo "Running tests"
  rules:
    - if: '$CI_COMMIT_BRANCH == "main"'
      when: always
    - if: '$CI_COMMIT_BRANCH =~ /^feature/'
      when: manual
    - when: never


#Runs automatically on main.
#Appears as manual job on feature/* branches.
# Skipped otherwise.

pipeline template

  • we can create multiple templates of common tasks, store them in a repo and basically combine and use them in an actual pipeline
  • it can act like a pipeline repository
  • in this the stage should be same as defined in the template
stage:
    - build
    - test
    - release
include:
    - project: "group/project/abc"
      ref: main
      file:
       - "build/mave.build.gitlab-ci.yml"
       - "test/mave.test.gitlab-ci.yml"
       - "release/mave.release.gitlab-ci.yml"

artifacts

  • since every job in gitlab runs in their own environment, to transfer anything from 1 job to other we use artifacts
  • reports are special type artifacts for structured reports that gitlab understand like dotenv, junit, sast, codequality etc
  • when decides when artifacts are uploaded:
    • always -> even if job fails
    • on_success -> only if job succeeds
    • on_failure -> only if job fails
  • exclude allows to exclude files
job1:
    script:
        - echo "hi" > example.txt
    artifacts:
        untracked: false
        when: on_success
        access: all
        expire_in: 30days
        paths:
            - "example.txt"
        exclude:
            - /a/b/*/c


job2:
    script:
        - echo example.txt
    needs:
        - "job1"
  • pass variable from 1 job to another using reports
job1:
    script:
        - echo "$MYVAR=helloworld" > set.env
    artifacts:
        reports:
            dotenv: set.env
job2:
    needs:
        - job1
    script:
        - echo $MYVAR
